String Level Arc Interrupter - PLC
Fonrich Arc Fault Circuit Interrupter (AFCI) is a UL 1699B-certified device engineered to deliver superior AFCI protection by detecting and interpreting arcing in ground-mounted PV systems. It effectively addresses arc issues by enabling arc fault detection at the string level, performing a targeted shutdown whenever an arc is detected.
Product Features & Advantages
This AFCI breaker system supports up to 1500V system voltages and accommodates unlimited string connections, offering exceptional flexibility for large-scale solar installations. Featuring real-time remote monitoring, it enhances AFCI protection performance, lowers maintenance costs, and complies with UL 1699B standards for arc fault circuit interrupters—making it a globally trusted solution for high-power PV environments.
Product Advantages
String-Level Arc Protection
Quickly detects and extinguishes arcs to protect the PV system
Voltage Up to 1500V
Arc Interrupter suppots 1500V Max. System Voltage
Remote Data Monitoring
Remote data monitoring via Fonrich platform
Flexible Configuration
No limitation on number of strings
Technical Parameter
Model
FR-AFCI-KNJC
Max. System Voltage
1500 V
Max. System Current
PLC / LoRa
Voltage Range For Operation
20 Vdc ~ 60 Vdc
Max. Number of Strings
1
Dimension
132×120×45 mm
Related Solutions
